MICROMASTER 420

Features:-
1. Easy installation
2. Easy commissioning
3. Rugged EMC design
4. Can be operated on IT line supplies
5. Fast repeatable response time to control signals
6. Comprehensive range of parameters enabling configuration for a wide range of applications
7. Simple cable connection
8. 1 Output relay
9. 1 Analog output (0 – 20 mA)
10. 3 Isolated and switchable NPN/PNP digital inputs
11. 1 Analog input, ADC: 0 – 10 V
The analog input can be used as the 4th digital input
12. BICO technology
13. Modular design for extremely flexible configuration
14. High switching frequencies for low-noise motor operation
15. Detailed status information and integrated message functions

This MICROMASTER 420 block is easily insert in your schematic diagram and connect as you like way.

The inverters are microprocessor-controlled and use state-of-the-art Insulated Gate BipoIar Transistor (IGBT) technology. This makes them reliable and versatile. A special pulse-width modulation method with selectable Pulse frequency permits quiet motor operation. Comprehensive protective functions provide excellent  inverter and motor protection. The MICROMASTER 420 with its default factory settings, is ideal for a large range of simple motor control applications. The MICROMASTER 420 can also be used for more advanced motor control applications via its comprehensive parameter lists. The MICROMASTER 420 can be used in both ‘stand-alone’ applications as well as being integrated into ‘Automation Systems’.
